Featuring state-of-the-art thermal sensors for detecting targets and advanced high-definition digital night vision for identifying them, the TNC225R excels in delivering superior operational effectiveness in various environments and conditions.
-TNC225R SPECIFICATIONS-
Physical Specifications
Net Weight
Dimensions
Storage
22.8oz
6.7*3.3*3.1 Inches
Internal Storage, 32GB
LRF Maximum Measuring Range
WIFI/APP
Bluetooth
5-1100yards
Yes
Yes
Ingress Protection
Operating Temperature
Shock Resistance
IP67
-4~122F
800Gs
Display Specifications
Type
Display Resolution
Frame Rate
Micro-OLED
1024*768 pixels
50FPS
Battery Power Supply
Battery Type
Operating Time
External Power Supply
18650 Battery(flat top)
5h
5V - Type C USB
THERMAL CHANNEL - Sensor Specifications
Resolution
Field of View(FOV)
Frame Rate
256x192px
7.03°x 5.28°
50FPS
Pixel Size
NETD
Focal Length of Objective Lens
12x12um
≤25mk@25℃
25mm
Base Magnification
Digital Zoom
Image Sensor
3X
3X,6X,9X,12X
Uncooled Infrared Image Sensor
VISIBLE LIGHT CHANNEL - Sensor Specifications
Resolution
Sensor Frame Rate
Video Record Resolution
1920*1080 pixels
60FPS
1024*768 pixels
VISIBLE LIGHT CHANNEL - Optical Specifications
Objective Lens Focal Length
Field of View(FOV)
Eye-Relief
52mm
6.13°x 3.45°
45mm/1.8 Inches
Base Magnification
Digital Zoom
Diopter Adjustment
5X
5X,7.5X,10X,12X,15X,17.5X,20X
±5D
IR Wavelength
Infrared Power
850/940nm
Class 3R Eye Safe
